INFO

Тип машины
Гусеничные экскаваторы
Марка / модель
CAT 307 E
Год выпуска
2024
Кол-во отработаного времени (моточасы)
500 ч
Страна местонахождения
Китай
Общая категория
1
2
3
4
5
Mascus ID
17EF953B

ЦЕНА

Выбор валюты

ПОДРОБНОСТИ

Складской номер
1
Тип двигателя
дизельный
Серийный номер
1
Количество владельцев
1
Последний тех осмотр
2025-06-27
Состояние ходовой части
Good Condition
Двигатель
Original
Масса
6 900 кг
Мощность двигателя
41,5 кВт (56,4 л.с.)
Engine manufacturer
Original
Регистрационный номер
1
Класс по нормам выхлопа
Ступень V
Объём ковша
0,33 м3
Ширина гусеницы
450 мм
Макс. гидропоток для доп.оборудования
147 л/мин
Макс. скорость
5,50 км/ч
Габариты (ДхШхВ)
6070 x 2300 x 2540 мм
Цвет
Original
Макс рабочая глубина
1 665 мм
Информация о состоянии/гарантия
1 Year
Страна производства
Америка
Условия доставки
FCA, FOB, CIF, EXW
Сертификаты
EPA, CE
Доп.оборудование
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.
Комплектация
Лебёдка для увязки сучков
- Кондиционер воздуха
- Дополнительная гидравлика
Предварительный фильтр двигателя
Показать все...
Прочая информация
Parameter configuration of Caterpillar 307E small Hydraulic Excavator Specification Power, traditional power Joint venture/import by manufacturers Bucket backhoe Tonnage (tons)7 The overall working weight of the machine (kg) is 6900 Bucket capacity (m³)0.33 Boom length (mm) : 3700 The length of the bucket pole (mm) is 1665 Performance Rotational speed (rpm) : 10.8 Rotational torque (Nm)16.3 Walking speed (km/h) : High: 5.1 / Low: 3.2 Climbing ability (%)60 The digging force of the bucket (kN) is 50.6 The digging force of the boom (kN) is 37.1 Maximum traction force (kN)56.9 Power system Engine model Cat C2.6DI Turbo Rated power (kw/rpm)41.5 Displacement (L)2.6 Bore × stroke (mm)87×110 Hydraulic system The main pump type is a load-sensing hydraulic system equipped with a variable displacement piston pump The maximum flow rate of the main pump (l/min) is 147 Walking hydraulic circuit (Mpa)28 Rotary hydraulic circuit (Mpa)24 The main overflow set pressure (Mpa) is 28 Oil capacity Fuel tank (L)135.0 Hydraulic oil tank (L)51.0 Hydraulic System (L)94.0 Engine oil change rate (L)10.2 Coolant (L)11.9 Main body size Total transportation length (mm) : 6070 Total transportation width (mm)2300 The total height of the cab (mm) is 2540 Track grounding length (mm)2120 The total length of the track (mm) is 2760 Track plate width (mm)450 Minimum ground clearance (mm)370 Counterweight ground clearance (mm)775 The rear end rotation radius (mm) is 1750 Scope of work Maximum excavation radius (mm) : 6300 The maximum excavation radius (mm) of the shutdown surface is 6180 Maximum excavation depth (mm) : 4070 Maximum excavation height (mm) : 7240 Maximum unloading height (mm) : 5190 The width × height (mm) of the push board is 2300×450 The lifting or pushing depth of the bulldozer blade (mm) is 390/350

上海吉潘贸易有限公司

上海市松江区车墩镇莘莘路32号3799 201600 上海 上海 Китай
